Canyon Ridge® Carriage House (5-Layer)

by

Insulated carriage house garage doors with faux wood-look composite overlays.

Contact us about this product

Beautiful and unique

Add character and charm to your home with Clopay's Canyon Ridge® Carriage House (5-Layer) garage door. Enjoy the authentic look of swing-out coach house doors paired with the modern-day functionality of upward operation. Not only beautiful, these doors provide quiet operation and energy efficiency for years to come.

Download Product Brochure

Overview

Clopay Canyon Ridge® Carriage House (5-Layer) garage doors take inspiration from the coach house designs of yesteryear and bring them to life with today's technology. These doors are constructed with steel for strength and durability, and molded composite materials for beauty and realism. The overlay material is molded from real wood boards to reproduce the unique grain patterns and textures of those species.

These low maintenance, faux wood doors are constructed with moisture-resistant, wood grain composite overlays and can be factory stained or painted in 7 colors, including black or slate. You can even combine the finishes for a truly unique look. These doors feature:

  • 5-layer construction: steel + insulation + steel + composite cladding + composite overlay.
  • Faux wood-look composite cladding and overlay materials are molded from actual wood pieces to reproduce the natural texture and intricate grain patterns of the species they emulate.
  • Colors include: Walnut, Dark, Medium, Slate, Black, White and Primed. (Additional Options)
  • 2" Intellicore® polyurethane insulation with a thermal break. R-Value of 20.4.
  • WINDCODE® door reinforcement product available for high wind load applications. (More Details

Environmental Assurance

Clopay doors are compliant with environmental laws and regulations. Clopay doors do not contain HFCs. All Clopay doors are compliant with:

  • California SB 1013
  • Washington HB 1112 – Hydrofluorocarbon Greenhouse Gas Emissions
  • Canadian regulations amending the ozone-depleting substances and halocarbon alternatives regulations
  • New Jersey A-5583/S-3919 – Greenhouse Gas Bill

Learn More In Our Buying Guide





Door Designs

SERIES 1

DESIGN 01
DESIGN 11
DESIGN 12
DESIGN 13

SERIES 2

DESIGN 21
DESIGN 22
DESIGN 23

SERIES 3

DESIGN 31
DESIGN 32
DESIGN 33
DESIGN 34
DESIGN 35
DESIGN 36
DESIGN 37
DESIGN 38
For more information regarding construction options per panel style, click here

Top Sections

SERIES 1 & 2 SOLID

Canyon Ridge LE TOP11
TOP11
Canyon Ridge LE TOP11
Canyon Ridge LE TOP12
TOP12
Canyon Ridge LE TOP12
Canyon Ridge LE TOP13
TOP13
Canyon Ridge LE TOP13
Canyon Ridge LE ARCH1 SOLID
ARCH1
Canyon Ridge LE ARCH1 SOLID

SERIES 1 & 2 WINDOW DESIGNS

Canyon Ridge LE REC11
REC11
Canyon Ridge LE REC11
Canyon Ridge LE REC13 Designs
REC13
Canyon Ridge LE REC13 Designs
Canyon Ridge LE REC14
REC14
Canyon Ridge LE REC14
Canyon Ridge LE SQ23
SQ23
Canyon Ridge LE SQ23
Canyon Ridge LE SQ24
SQ24
Canyon Ridge LE SQ24
Canyon Ridge Limited Edition ARCH1 with Window
ARCH1
Canyon Ridge Limited Edition ARCH1 with Window
Canyon Ridge LE ARCH3 Designs 11-12-13-21-22-23
ARCH3
Canyon Ridge LE ARCH3 Designs 11-12-13-21-22-23
Canyon Ridge LE ARCH4 Designs 11-12-13-21-22-23
ARCH4
Canyon Ridge LE ARCH4 Designs 11-12-13-21-22-23
Canyon Ridge Limited Edition ARCH13
ARCH13
Canyon Ridge Limited Edition ARCH13
Canyon Ridge Limited Edition ARCH14
ARCH14
Canyon Ridge Limited Edition ARCH14

DOUBLE TOP SECTIONS

CrARC1A - CR LE
ARC1A - SOLID (Double Door)
CrARC1A - CR LE
CrARC1AWindow-DF-CC-Dbl - CR LE
ARC1A - WINDOW (Double Door)
CrARC1AWindow-DF-CC-Dbl - CR LE
CrARC3A-DF-CC-Dbl
ARC3A - WINDOWS (Double Door)
CrARC3A-DF-CC-Dbl
CrARC4A-DF-CC--Dbl
ARC4A - WINDOWS (Double Door)
CrARC4A-DF-CC--Dbl
Canyon Ridge Limited Edition ARC13A
ARC13A - WINDOWS (DOUBLE DOOR)
Canyon Ridge Limited Edition ARC13A
Canyon Ridge Limited Edition ARC14A
ARC14A - WINDOWS (DOUBLE DOOR)
Canyon Ridge Limited Edition ARC14A

Colors

MEDIUM FINISH
DARK FINISH
WALNUT FINISH
SLATE FINISH
BLACK FINISH*
WHITE FINISH*
PRIMED(NO FINISH)
BRONZE*
CHARCOAL*

*Available on select models. For more information regarding color availability, click here.

Two-tone option available. One color for the base layer (steel) and one color for the top layer (composite overlay).

Canyon Ridge 5-Layer

Custom color available through ColorBlast® program.

Hardware Designs

HANDLES

SPADE LIFT HANDLES
(included)
SPEAR LIFT HANDLES
COLONIAL LIFT HANDLES
DECORATIVE LIFT HANDLES
RING DOOR KNOCKER
ESCUTCHEON PLATE(S)
TWISTED "L" HANDLES

HINGES

SPADE STRAP HINGE
SPEAR STRAP HINGE
COLONIAL STRAP HINGE

PLATES

SPADE STEP PLATE
SPEAR STEP PLATE
COLONIAL STEP PLATE

Clopay Canyon Ridge® Carriage House (5-Layer) garage doors are built five layers strong. The faux wood-look composite overlay and cladding surface are low maintenance, durable and won't rot, warp, or crack.

canyon ridge limited edition construction cutaway
intellicore header
Warmer. Quieter. Stronger.
Garage doors featuring Intellicore® insulation technology represent the ultimate smart choice for homeowners. Clopay’s Intellicore® is a proprietary polyurethane foam that is injected into a garage door, expanding to fill the entire structure. The result is a door with incredible strength, energy efficiency, and durability. (Click for details)
  • Door sample shown in Walnut Finish.
  • Replaceable vinyl bottom weather seal in rust free aluminum retainer helps protect against the elements.
  • High performance nylon ball bearing rollers help ensure smooth, long-lasting, quiet operation.
  • Heavy-duty 14 gauge steel hinges and brackets for smooth and worry-free operation.
  • Window grilles are removable for easy cleaning.
  • Safe-T-Bracket® - Prevents serious injury that could occur if the bottom bracket were removed with the garage door closed and under tension.
  • Product complies with 2015 IECC air infiltration requirement of 0.40 cfm/ft2 or less (IECC, Section C402.5.2)
